LCD IPS HDR MONITOR MISURA M16TB – 16" with built-in 8000 mAh battery
Do you travel often and run out of screen space on a small laptop? Then the MISURA M16TB 16" portable touchscreen monitor with a built-in 8000 mAh battery is the right choice for you, lasting up to 4 hours without needing to be plugged in. It combines a large 16" display with excellent HDR colour performance. Plus, it features tempered glass with a touch layer for easy control.
Touch control is compatible with Windows, Linux and Apple iOS.
Key features
- Compact size, ultra-thin bezel and weight of just 1.0 kg
- Built-in 8000 mAh battery – up to 4 hours without connecting to power
- Excellent colour reproduction from any viewing angle (IPS)
- Sharp, detailed image thanks to Full HD resolution (1920 × 1080)
- High-quality touchscreen with G+G technology
- HDR (High Dynamic Range) – high dynamic range colour
- Built-in speakers for surround sound
- Reduced blue light emission – Low Blue Mode
Built-in battery, light weight
The MISURA M16TB – 16" WLED monitor stands out with its low weight of 1.0 kg and slim 9 mm profile. Thanks to the ultra-thin bezel, its overall dimensions are only 22.4 × 36 × 1 cm. To use the monitor, you only need a single USB-C cable, which handles both video transfer and power.
If your computer does not have this connector, you can use a combination of HDMI (for video signal) and USB-A (for power). The necessary cables are included in the standard package.
This model is also equipped with a built-in 8000 mAh battery, providing up to 4 hours of operation without external power. This makes it easy to use with almost any device, including mobile phones and gaming consoles.
Full HD resolution (1920 × 1080)
The MISURA M16TB – 16" monitor features a Full HD resolution (1920 × 1080), ensuring a perfectly sharp image. The visual experience is enhanced by IPS technology, which delivers excellent colour reproduction even when viewed from a wide angle.
On the move, MISURA M16TB – 16" portable monitors give you the comfort of your own desk.
Full G+G lamination technology
This optical adhesive lamination technology completely removes air between the touch screen and the display panel across the entire surface. It significantly reduces light reflection and transmitted-light loss, which increases brightness and improves the display effect.
Full lamination also significantly extends the device’s lifespan. The air layer created by conventional bonding can easily be contaminated by dust and water vapour during use. Our G+G technology fully fills all gaps, tightly bonding the display panel and the touch layer together.
Dust and water vapour have nowhere to penetrate, keeping the screen clean for a long time.
| Diagonal | 16" |
|---|---|
| Monitor type | Portable - single |
| Screen | Flat |
| Resolution | 1920 × 1080 |
| Touch screen | YES |
| Panel Technology | LCD |
| Backlight | LED |
| Panel Type | IPS |
| Aspect ratio | 16:9 |
| Colours | 16.7 million colours |
| Contrast | 1200:1 |
| Refresh rate | 60 Hz |
| Brightness | 300 cd/m² |
| Colour coverage | 81 % sRGB (58 % NTSC) |
| FreeSync | NO |
| Response time | 30 ms |
| Viewing Angle | 178° (H) / 178° (V) |
| Flicker-Free | NO |
| G-sync Compatible | NO |
| Low Blue Light | YES |
| OverDrive | NO |
| HDR10 | YES |
| Built-in battery | Li-ion 8000 mAh |
| RGB Light | NO |
| Height Adjustable Stand (HAS) | NO |
| VESA | NO |
| Speaker | 2× 1 W |
| Connectors | 1× HDMI, 2× USB-C |
| Power Delivery (PD) | 15 W |
| Material | Aluminium alloy |
| Color |
|
| Weight | 1,00 kg |
| PiP/PbP | NO |
| Headphone Jack | YES |
| Battery life | 4,5 hours |
| Pivot | NO |
| Width (cm) | 36,0 |
| Height (cm) | 22,4 |
| Depth (cm) | 0,9 |
| eDP | 1.2 |
| Certificates | CE, RoHS |
| Package contents | 1× USB-C → USB-C cable, 1× Portable monitor 16" with built-in 8000 mAh battery, 1× USB-C → USB-A cable, 1× miniHDMI → HDMI cable, 1× Charger, 1× Magnetic protective case |
